CS1 Multi-tone alarm sounder with LED flashing light indicator

Downloads

CS1 Multi-tone alarm sounder with LED flashing light indicator

Cost-effective multi-tone alarm sounder with LED flashing beacon
32 tones can be selected via DIP switch
Sound pressure can be preselected in 3 steps via DIP switch

For universal applications at 24 V DC
Second tone can be switched externally
Degree of protection IP 65 can be achieved if installed correctly

Especially suitable for

Electrical wholesale trade

Technical data

Housing	Ø 63 mm, red or white
Lens	ribbed inside amber or red
Type of mounting	horizontal, vertical or any
Beacon type	LED flashing beacon
Strobe/flash frequency	1 Hz
Tone	32 Tones, 2 Tones can be switched externally, various (see tone table)
Volume	88-109 dB (can be adjusted with potentiometer)
Tone frequency	440-2.900 Hz
Duty cycle	100 %
Service life	Light source: >50.000 h
Operating temperature	-20 °C / +70 °C
Degree of protection	IP65
Weight	258 g
